AE 503 Indicator-AE 503

Capacity
Selectable
View alternative models
The AE 503 label printing indicator combines weighing applications and a printer in one easy-to-use device, providing an ideal solution for manufacturing, packing and distribution needs.
Warranty 3 years

Applications

  • WeighingWeighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • CheckweighingCheckweighing
  • Check countingCheck counting
  • Dynamic / animal weighingDynamic / animal weighing
  • AccumulationAccumulation
  • Display holdDisplay hold
  • AveragingAveraging
  • Peak holdPeak hold

Features

  • Backlit DisplayBacklit Display
  • TareTare
  • Battery PowerBattery Power
  • RS-232RS-232
  • External CalibrationExternal Calibration
  • DateDate
  • TimeTime
  • Built-in PrinterBuilt-in Printer
  • Multiple Weighing unitsMultiple Weighing units
Toggle icon descriptions
Strong ABS construction and an integrated label printer enhance functionality for the AE 503 label printing indicator, making it an ideal option for weighing, parts counting, percentage weighing, dynamic weighing, check counting, checkweighing and averaging. A large, easy-to-read backlit LCD screen features 34mm-tall digits and symbols to show over, under or within limits during checkweighing. A sealed, color-coded keypad allows quick and easy configuration. Using the built-in printer, add barcodes, QR codes, pictures and custom logos to the 50mm-wide printed labels.

Features and Benefits

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • RS-232 interface provides speedy connection to computers and printers
  • Rugged construction stands up to industrial use
  • Built-in printer can print weight, QR codes, bar codes and customized labels in numerous languages
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • Zero-tracking feature ensures display returns to zero reading
  • Parts counting optimisation automatically refines piece weight as parts are added
  • Checkweighing with audible alarm
  • External calibration allows for verification and adjustment with weights
  • Quick and easy configuration using the keypad
  • User-selectable scale division
  • 1:600,000 internal counting resolution
  • A 3-year warranty means quality assured for years of use.

Technical specification

Model

AE 503

UPC: 840886105570

Metrology

  • Capacity
    • Selectable

General Specifications

  • Weighing Units
    • ct, dr, g, kg, lb, mm, oz, T, tonne
  • Stabilisation Time
    • 2
  • Interface
    • RS-232
  • Calibration
    • External calibration
  • Display
    • Backlit LCD with 34mm high digits
  • PLU memories
    • 0

Power

  • Power Supply
    • 12VDC 3A adapter / Internal rechargeable battery
  • Battery type
    • Lead Acid
  • Number of batteries
    • 1
  • Maximum Battery Life (in hours)
    • 200

Operating Conditions

  • Operating Temperature
    • 0° to 40°C / 32° to 104°F

Product Information

  • Construction
    • ABS plastic
  • Net Weight
    • 3.5kg

Dimensions

  • Overall dims
    • 300x125x170mm
